Example Productivity Suite Deployment on Intel® Xeon® Platform¶
This document outlines the deployment process for OPEA Productivity Suite utilizing the GenAIComps microservice pipeline on Intel Xeon server.This example includes the following sections:
Productivity Suite Quick Start Deployment: Demonstrates how to quickly deploy a Productivity Suite service/pipeline on Intel® Xeon® platform.
Productivity Suite Docker Compose Files: Describes some example deployments and their docker compose files.
Productivity Suite Service Configuration: Describes the service and possible configuration changes.
Productivity Suite Quick Start Deployment¶
This section describes how to quickly deploy and test the Productivity Suite service manually on Intel® Xeon® platform. The basic steps are:
Access the Code¶
Clone the GenAIExample repository and access the Productivity Suite Intel® Xeon® platform Docker Compose files and supporting scripts:
git clone https://github.com/opea-project/GenAIExamples.git
cd GenAIExamples/ProductivitySuite/docker_compose/intel/cpu/xeon/
Checkout a released version, such as v1.3:
git checkout v1.3
Generate a HuggingFace Access Token¶
Some HuggingFace resources, such as some models, are only accessible if you have an access token. If you do not already have a HuggingFace access token, you can create one by first creating an account by following the steps provided at HuggingFace and then generating a user access token.
Configure the Deployment Environment¶
To set up environment variables for deploying Productivity Suite service, source the set_env.sh script in this directory:
source set_env.sh
The set_env.sh script will prompt for required and optional environment variables used to configure the Productivity Suite service. If a value is not entered, the script will use a default value for the same. It will also generate a env file defining the desired configuration. Consult the section on Productivity Suite Service configuration for information on how service specific configuration parameters affect deployments.
Deploy the Service Using Docker Compose¶
To deploy the Productivity Suite service, execute the docker compose up command with the appropriate arguments. For a default deployment, execute:
docker compose up -d
The Productivity Suite docker images should automatically be downloaded from the OPEA registry and deployed on the Intel® Xeon® Platform:
[+] Running 19/19
✔ Network xeon_default Created 0.1s
✔ Container tgi-service Healthy 165.2s
✔ Container promptregistry-mongo-server Started 1.0s
✔ Container redis-vector-db Started 1.7s
✔ Container tei-reranking-server Healthy 61.5s
✔ Container chathistory-mongo-server Started 1.7s
✔ Container tgi_service_codegen Healthy 165.7s
✔ Container tei-embedding-server Healthy 12.0s
✔ Container keycloak-server Started 0.8s
✔ Container whisper-server Started 1.4s
✔ Container productivity-suite-xeon-react-ui-server Started 2.1s
✔ Container mongodb Started 1.2s
✔ Container dataprep-redis-server Healthy 22.9s
✔ Container retriever-redis-server Started 2.2s
✔ Container llm-textgen-server-codegen Started 166.0s
✔ Container docsum-xeon-llm-server Started 165.5s
✔ Container codegen-xeon-backend-server Started 166.3s
✔ Container docsum-xeon-backend-server Started 165.9s
✔ Container chatqna-xeon-backend-server Started 165.9s
Check the Deployment Status¶
After running docker compose, check if all the containers launched via docker compose have started:
docker ps -a
For the default deployment, the following 5 containers should be running:
CONTAINER ID IMAGE COMMAND CREATED STATUS PORTS NAMES
8e3c0e9398ae opea/chatqna:latest "bash entrypoint.sh" 8 minutes ago Up 5 minutes 0.0.0.0:8888->8888/tcp, :::8888->8888/tcp chatqna-xeon-backend-server
cc317e6feb89 opea/docsum:latest "python docsum.py" 8 minutes ago Up 5 minutes 0.0.0.0:8890->8888/tcp, :::8890->8888/tcp docsum-xeon-backend-server
683dd7cacef2 opea/codegen:latest "python codegen.py" 8 minutes ago Up 5 minutes 0.0.0.0:7778->7778/tcp, :::7778->7778/tcp codegen-xeon-backend-server
a38d8d906cd0 opea/llm-docsum:latest "python opea_docsum_…" 8 minutes ago Up 5 minutes 0.0.0.0:9003->9000/tcp, :::9003->9000/tcp docsum-xeon-llm-server
f0a61333ae16 opea/llm-textgen:latest "bash entrypoint.sh" 8 minutes ago Up 5 minutes 0.0.0.0:9001->9000/tcp, :::9001->9000/tcp llm-textgen-server-codegen
a942446f47c1 opea/dataprep:latest "sh -c 'python $( [ …" 8 minutes ago Up 8 minutes (healthy) 0.0.0.0:6007->5000/tcp, :::6007->5000/tcp dataprep-redis-server
f77b9b69fcaf opea/retriever:latest "python opea_retriev…" 8 minutes ago Up 8 minutes 0.0.0.0:7001->7000/tcp, :::7001->7000/tcp retriever-redis-server
0324b9efd729 opea/productivity-suite-react-ui-server:latest "/docker-entrypoint.…" 8 minutes ago Up 8 minutes 0.0.0.0:5174->80/tcp, :::5174->80/tcp productivity-suite-xeon-react-ui-server
747e09a5afea ghcr.io/huggingface/text-generation-inference:2.4.0-intel-cpu "text-generation-lau…" 8 minutes ago Up 8 minutes (healthy) 0.0.0.0:8028->80/tcp, :::8028->80/tcp tgi_service_codegen
ea7444faa8b2 ghcr.io/huggingface/text-generation-inference:2.4.0-intel-cpu "text-generation-lau…" 8 minutes ago Up 8 minutes (healthy) 0.0.0.0:9009->80/tcp, :::9009->80/tcp tgi-service
8fdb186853ac opea/whisper:latest "python whisper_serv…" 8 minutes ago Up 8 minutes 0.0.0.0:7066->7066/tcp, :::7066->7066/tcp whisper-server
7982f2d1ff89 mongo:7.0.11 "docker-entrypoint.s…" 8 minutes ago Up 8 minutes 0.0.0.0:27017->27017/tcp, :::27017->27017/tcp mongodb
9fb471c452ec quay.io/keycloak/keycloak:25.0.2 "/opt/keycloak/bin/k…" 8 minutes ago Up 8 minutes 8443/tcp, 0.0.0.0:8080->8080/tcp, :::8080->8080/tcp, 9000/tcp keycloak-server
a00ac544abb7 ghcr.io/huggingface/text-embeddings-inference:cpu-1.6 "/bin/sh -c 'apt-get…" 8 minutes ago Up 8 minutes (healthy) 0.0.0.0:6006->80/tcp, :::6006->80/tcp tei-embedding-server
87c2996111d5 redis/redis-stack:7.2.0-v9 "/entrypoint.sh" 8 minutes ago Up 8 minutes 0.0.0.0:6379->6379/tcp, :::6379->6379/tcp, 0.0.0.0:8001->8001/tcp, :::8001->8001/tcp redis-vector-db
536b71e4ec67 opea/chathistory-mongo:latest "python opea_chathis…" 8 minutes ago Up 8 minutes 0.0.0.0:6012->6012/tcp, :::6012->6012/tcp chathistory-mongo-server
8d56c2b03431 opea/promptregistry-mongo:latest "python opea_prompt_…" 8 minutes ago Up 8 minutes 0.0.0.0:6018->6018/tcp, :::6018->6018/tcp promptregistry-mongo-server
c48921438848 ghcr.io/huggingface/text-embeddings-inference:cpu-1.6 "/bin/sh -c 'apt-get…" 8 minutes ago Up 8 minutes (healthy) 0.0.0.0:8808->80/tcp, :::8808->80/tcp tei-reranking-server
Setup Keycloak¶
Please refer to keycloak_setup_guide for more detail related to Keycloak configuration setup.
Test the Pipeline¶
Once the Productivity Suite service are running, test the pipeline using the following command:
ChatQnA MegaService
curl http://${host_ip}:8888/v1/chatqna -H "Content-Type: application/json" -d '{
"messages": "What is the revenue of Nike in 2023?"
}'
DocSum MegaService
curl http://${host_ip}:8890/v1/docsum -H "Content-Type: application/json" -d '{
"messages": "Text Embeddings Inference (TEI) is a toolkit for deploying and serving open source text embeddings and sequence classification models. TEI enables high-performance extraction for the most popular models, including FlagEmbedding, Ember, GTE and E5.",
"type": "text"
}'
CodeGen MegaService
curl http://${host_ip}:7778/v1/codegen -H "Content-Type: application/json" -d '{
"messages": "def print_hello_world():"
}'
Cleanup the Deployment¶
To stop the containers associated with the deployment, execute the following command:
docker compose -f compose.yaml down
[+] Running 19/19
✔ Container mongodb Removed 0.5s
✔ Container codegen-xeon-backend-server Removed 10.4s
✔ Container docsum-xeon-backend-server Removed 10.6s
✔ Container whisper-server Removed 1.3s
✔ Container promptregistry-mongo-server Removed 10.8s
✔ Container chatqna-xeon-backend-server Removed 11.0s
✔ Container productivity-suite-xeon-react-ui-server Removed 0.6s
✔ Container keycloak-server Removed 0.7s
✔ Container chathistory-mongo-server Removed 10.9s
✔ Container llm-textgen-server-codegen Removed 10.4s
✔ Container docsum-xeon-llm-server Removed 10.4s
✔ Container tei-reranking-server Removed 13.0s
✔ Container tei-embedding-server Removed 12.8s
✔ Container dataprep-redis-server Removed 12.9s
✔ Container retriever-redis-server Removed 12.3s
✔ Container tgi_service_codegen Removed 3.1s
✔ Container tgi-service Removed 3.1s
✔ Container redis-vector-db Removed 0.5s
✔ Network xeon_default Removed 0.3s
All the Productivity Suite containers will be stopped and then removed on completion of the “down” command.
Productivity Suite Docker Compose Files¶
The compose.yaml is default compose file using tgi as serving framework
Service Name |
Image Name |
|---|---|
chathistory-mongo-server |
opea/chathistory-mongo:latest |
chatqna-xeon-backend-server |
opea/chatqna:latest |
codegen-xeon-backend-server |
opea/codegen:latest |
dataprep-redis-server |
opea/dataprep:latest |
docsum-xeon-backend-server |
opea/docsum:latest |
docsum-xeon-llm-server |
opea/llm-docsum:latest |
keycloak-server |
quay.io/keycloak/keycloak:25.0.2 |
llm-textgen-server-codegen |
opea/llm-textgen:latest |
mongodb |
mongo:7.0.11 |
productivity-suite-xeon-react-ui-server |
opea/productivity-suite-react-ui-server:latest |
promptregistry-mongo-server |
opea/promptregistry-mongo:latest |
redis-vector-db |
redis/redis-stack:7.2.0-v9 |
retriever-redis-server |
opea/retriever:latest |
tei-embedding-server |
ghcr.io/huggingface/text-embeddings-inference:cpu-1.6 |
tei-reranking-server |
ghcr.io/huggingface/text-embeddings-inference:cpu-1.6 |
tgi_service_codegen |
ghcr.io/huggingface/text-generation-inference:2.4.0-intel-cpu |
tgi-service |
ghcr.io/huggingface/text-generation-inference:2.4.0-intel-cpu |
whisper-server |
opea/whisper:latest |
Productivity Suite Service Configuration¶
The table provides a comprehensive overview of the Productivity Suite service utilized across various deployments as illustrated in the example Docker Compose files. Each row in the table represents a distinct service, detailing its possible images used to enable it and a concise description of its function within the deployment architecture.
Service Name |
Possible Image Names |
Optional |
Description |
|---|---|---|---|
chathistory-mongo-server |
opea/chathistory-mongo:latest |
No |
Handles chat history storage and retrieval using MongoDB. |
chatqna-xeon-backend-server |
opea/chatqna:latest |
No |
Handles question answering and chat interactions. |
codegen-xeon-backend-server |
opea/codegen:latest |
No |
Handles code generation tasks. |
dataprep-redis-server |
opea/dataprep:latest |
No |
Handles data preparation and preprocessing tasks for downstream services. |
docsum-xeon-backend-server |
opea/docsum:latest |
No |
Handles document summarization tasks. |
docsum-xeon-llm-server |
opea/llm-docsum:latest |
No |
Handles large language model (LLM) based document summarization. |
keycloak-server |
quay.io/keycloak/keycloak:25.0.2 |
No |
Handles authentication and authorization using Keycloak. |
llm-textgen-server-codegen |
opea/llm-textgen:latest |
No |
Handles large language model (LLM) text generation tasks, providing inference APIs for code and text completion. |
mongodb |
mongo:7.0.11 |
No |
Provides persistent storage for application data using MongoDB. |
productivity-suite-xeon-react-ui-server |
opea/productivity-suite-react-ui-server:latest |
No |
Hosts the web-based user interface for interacting with the Productivity Suite services. |
promptregistry-mongo-server |
opea/promptregistry-mongo:latest |
No |
Manages storage and retrieval of prompt templates and related metadata. |
redis-vector-db |
redis/redis-stack:7.2.0-v9 |
No |
Offers in-memory data storage and vector database capabilities for fast retrieval and caching. |
retriever-redis-server |
opea/retriever:latest |
No |
Handles retrieval-augmented generation tasks, enabling efficient document and context retrieval. |
tei-embedding-server |
ghcr.io/huggingface/text-embeddings-inference:cpu-1.6 |
No |
Provides text embedding and sequence classification services for downstream NLP tasks. |
tei-reranking-server |
ghcr.io/huggingface/text-embeddings-inference:cpu-1.6 |
No |
Performs reranking of retrieved documents or results using embedding-based similarity. |
tgi_service_codegen |
ghcr.io/huggingface/text-generation-inference:2.4.0-intel-cpu |
No |
Serves code generation models for inference, optimized for Intel Xeon CPUs. |
tgi-service |
ghcr.io/huggingface/text-generation-inference:2.4.0-intel-cpu |
No |
Specific to the TGI deployment, focuses on text generation inference using Xeon hardware. |
whisper-server |
opea/whisper:latest |
No |
Provides speech-to-text transcription services using Whisper models. |
